Description
Features:
- Independent detachable lens plug for FPV and visual observation flights
- Wings with embedded carbon fiber rods at different angles
- Compact wingspan with spacious electronics compartment
- Four magnets for secure hatch fastening
- Wingtip design for vertical take-off mode
- Horizontal and vertical battery mounting options
- Tailored lens ring for enhanced protection
- New propeller locking method
- Tailored for DJI Digital Air unit
Specifications:
- Airplane dimensions: Wingspan 690mm, Height 88mm, Length 415mm
- Fuselage space: Battery compartment 175mm x 175mm x 55mm
- VTX fixed seat: Compatible with digital and analog VTX
- KIT weight: 150g (EPP-30)/190g (EPP-20)
- ESC compartment: 70mm x 38mm x 20mm
- Materials: EPP/ABS/Carbon Fiber
- Max Flight speed: ≥220km/h
- Max Endurance: >70 minutes
- Take-off weight: 350g - 850g
- Min Flight speed: <27km/h
- Thrust: ≥920g (6 x 4E prop)
- Propeller: 5 x 5E/6 x 4E
- Max Mileage: >45km
- Battery: 2S - 4S
- Note: Lens cover recommended when speed is ≥100km/h to prevent excessive inflow air from blowing away the hatch.
PNP Youth Edition:
- Motor: 2204-2200kv brushless x 1
- ESC: FTC 20A brushless/2A UBEC build-in x 1
- Propeller: 5045 x 2
- Servo: digital 9g x 2
- Hee Wing RX-1.0 flight controller x 1
