RadioMaster Zorro Max Transmitter 4 in 1 Radio Controller

RadioMasterSKU: RMS-0041-BLK

Color: Black
Price:
Sale price$219.00

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Download Manual

Description

RadioMaster Zorro Max Transmitter 4 in 1 Radio Controller

Features

  • Optional 4 colors - Red/Blue/Gold/Black
  • AG01 MINI hall gimbals installed
  • Carbon Fiber pattern body
  • Improved CNC parts as standard
  • Upgraded Black Leather Grips
  • External Module Bay for use with Crossfire / EL RS and other compatible modules
  • Available in 4in1 and ExpressLRS Versions
  • Supports OPENTX & EDGETX
  • 18350 Battery Compartments
  • Oversized LCD with adjustable brightness for any environment

Specification

  • Item: Zorro Max Radio
  • Color: Red / Blue / Gold / Black
  • Gimbals: AG01 MINI Gimbals
  • Physical Dimensions: 170*159*108mm
  • Weight: 350 grams
  • Operating Frequency: 2.400GHz-2.480GHz
  • Internal RF Options: 4-in-1 multi-protocol / ELRS
  • Supported Protocols: Module dependent / ELRS
  • RF Power: 4-in-1: 20dBm max. ELRS: Up to 250mw ( CE & FCC Versions will be available)
  • Antenna Gain: Folding 2db
  • Operational Current: 160mA@8.4V
  • Operational Voltage: 6.6-8.4v DC
  • Control Distance: 4-in-1:> 2km @ 20dbm / ELRS: Receiver and Power Output dependant
  • Operating system: OpenTX / EdgeTX Compatible
  • Control channels: Maximum 16 (Rx dependent)
  • Display: 128*64 Monochrome LCD
  • Battery: 2 x 18350 (Not included)
  • Charging: Built in USB-C Charging
  • Module Bay: Nano Size (Compatible with TBS Nano Crossfire / Nano Tracer / IRC Ghost)
  • Firmware Upgrade Method: Via USB or SD card

Package Includes

  • 1 * Zorro Max Radio
  • 1 * Screen Protector
  • 1 * USB-C Cable
  • 1 * Stickers
  • 1 * Manual
