Availability: 36 In Stock
Sku: HEE-F01-PNP

Independent detachable lens plug for both FPV and visual observation flights
Wings have embedded carbon fiber rods with different angles
Small wingspan with large space for electronics electronics
Four magnets are applied to the hatch for better fastening
The new wingtip design supports vertical take-off mode
Supports horizontal and vertical battery mounting
Tailored lens ring for better protection
All new propeller locking method
Tailored for DJI Digital Air unit

Airplane Dimension: Wingspan 690mm, Height: 88mm, Length: 415mm
Fuselage space: Battery compartment: 175mm*175mm*55mm
VTX fixed seat: compatible with digital VTX and analog VTX
KIT Weight: 150g (epp-30)/190g (epp-20)
ESC compartment: 70mm*38mm*20mm
Material : EPP/ABS/Carbon Fiber
Max Flight speed: ≥220+km/h
Max Endurance: >70 minutes
Take off weight: 350g~850g
Min Flight speed: <27km/h
Thrust: ≥920g(6*4E prop)
Propeller: 5x5E/6x4E
Max Mileage: >45km
Battery: 2S~4
Note: when speed is≥100km/h, should install lens cover to prevent excessive inflow air from blowing away from the hatch.

PNP Youth Edition :
Motor: 2204-2200 kv brushless*1
ESC: FTC 20A brushless/2A UBEC build-in*1
Propeller: 5045*2
Servo: digital 9g*2
Hee Wing RX-1.0 flight controller*1
