OMP Hobby 74" Edge 540 Kevlar Reinforced Balsa 3D Airplane ARF

Roll over image to zoom in Click on image to zoom

OMP Hobby 74" Edge 540 Kevlar Reinforced Balsa 3D Airplane ARF

Name: OMP Hobby 74" Edge 540 Kevlar Reinforced Balsa 3D Airplane ARF
Brand: OMPHOBBY
SKU: OMP-Edge-74-ARF-Y
Price: 699.99 USD
Availability: OutOfStock
Rating: 4.78 (9 reviews)

OMPHOBBYSKU: OMP-Edge-74-ARF-Y

Color: YELLOW

Variant

Price:

$699.99

Quantity:

First time to order from your store. Received the Edge 540 very fast. Great price for a great airplane. I’m almost finished with it . Looking forward to maiden flight. Going to order another one in a couple of weeks. Thanks

OMP Edge 540 74in.

Top of the line Plane on par with the big boys and better. Well constructed with all the latest innovations in RC Planes. Great flyer with my DLE 35RA motor installed swinging 20x8 or a 19x10 prop. Top speed was recorded at 95.5mph on straight level flight. Thrust to weight ratio seems perfect for any type flying you may choose. Hope to enjoy this plane for many years. Buddy RC ships fast, ordered on a Saturday and received on Wednesday. Can't go wrong with Buddy RC and OMP !!!!!!!

Edge Review

As with a few other customers I struggled trying to get the combo I wanted. I powered mine with the Scorpion A-5025 415KV
ESC is the Scorpion Tribunus III
160 amp swinging a 20X8 prop.
Powered by a single 6C 5000 100c Battery. Pull Pull Rudder setup and CG was spot on. I also went with the Scorpion battery back up as well. Airplane maiden with one click to ailerons. Plane flys great and no strange behaviors. I’ve got a few planes in my stable 30-35% gassers and I look at this one first on loading the vehicle just a solid flyer! This is definitely a plane worth looking at.

Very well built and finished airplane.

I have yet to complete the build of this model, but first impressions are this is a great model. Overall construction is great with the best ARF covering finish that I have seen.
Buddy RC customer service has been fantastic. I received my package one day after ordering. That is fast service.

74” OMP Edge 540

What a great looking plane! The workmanship is one of the best I’ve seen in years, I ordered one a year ago and I must say this is one of my favorite planes in my collection! At the field, a lot of my club members were very impressed, so much so that I ordered one for our clubs Christmas party as a door raffle! 👍🏻

1 2

Share this product

Instruction manual of OMP Hobby 74" Edge

This is an oversized box and does not qualify for free shipping. Flat rate shipping applied at checkout.
Parameter Specification

Item：	OMPHOBBY 74” EDGE 540	Color:	Green▢ Red▢ Yellow▢ Orange▢
WingSpan:	1880mm(74in)	Full Length:	1800mm(71in)
Flight Weight:	4.8~5.3KG	The Center of Gravity (CG)：	Approx.120-135mm
Wing Area:	70.51g/d㎡	Wing Load:	68~75.1g/d㎡
Wing Angle of Incidence:	0°	Motor Thrust Angles:	Down 0° & Right 2°
Pack Dimension：	1445630(LHW)cm	Gross Weight:	15.3kg
Servo: 20~35 Kg5 (Aileron 2, Elevator1 Rudder1 Throttle*1), Servo Arm: 1.5" 25T Servo Arm
Gas Power (Recommended): 30-35CC, Propeller: 19x8/19x9/19x10/20x8/20x9
Electric Power (Recommended): Option 1: Motor: Sunnysky 7015, ESC: X120A, Propeller:20x8/20x9, Lipo 8s 4000mah/12s 3300mah 3700mah 4000mah Option 2: Motor: Sunnysky 6220, ESC: X120A, Propeller:20x8/20x9 ; Lipo 6S 5000mah /8s 3300mah 3700mah 4000mah

Recommended Settings of Dual Rates and Exponentials of Control Surfaces

	Rate	EXP	Direction	Throw
Aileron	High	35~40%	Up	36~39°
Aileron	Low	40~45%	Down	20~26°
Elevator	High	38~45%	Up	45~53°
Elevator	Low	45~55%	Down	30~35°
Rudder	High	38~45%	Up	42~50°
Rudder	Low	45~55%	Down	28~32°
