$11.99
Availability: 125 In Stock
Sku: SS-R1106-6500
[TABS]OVERVIEW

KV5500
Stator Diameter 11mm Weight 7.5g
Stator Thickness 6mm Rotor Diameter 14.2mm
No.of Stator Slots 9 Body Length 13.6mm
No.of Rotor Poles 12 Max Lipo Cell 3-4S
Motor Kv 5500 ESC 15-20A
No-load current 0.6A/10V Recommended Prop(inch) 2035*4/3020*2
Motor Resistance 185mΩ



Max Continuous Current 14.5A/15s
Max Continuous Power 240W



Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
GF2035*4 11.1 0.7 20 8 2.57 73℃
1.6 40 18 2.25
2.42 60 27 2.23
3.25 80 36 2.22
4.17 100 46 2.16
5.1 120 57 2.12
6 140 67 2.10
8.6 188 95 1.97
12.5 0.7 20 9 2.29
1.5 40 19 2.13
2.3 60 29 2.09
3.1 80 39 2.06
4 100 50 2.00
4.9 120 61 1.96
5.8 140 73 1.93
7.6 180 95 1.89
10.1 228 126 1.81
14.8 0.7 20 9 2.23
1.41 40 18 2.22
2.2 60 28 2.13
3 80 38 2.08
3.9 100 50 2.00
4.83 120 62 1.94
5.8 140 74 1.89
7.5 180 96 1.88
10.4 237 133 1.78
16.5 0.5 20 8 2.42
1.2 40 20 2.02
2 60 33 1.82
2.7 80 45 1.80
3.5 100 58 1.73
4.4 120 73 1.65
5.3 140 87 1.60
7.1 180 117 1.54
8.8 220 145 1.52
10.7 260 177 1.47
12.4 300 205 1.47
14.1 337 233 1.45
3020*2 11.1 0.5 20 6 3.60 61℃
1.05 40 12 3.43
1.7 60 19 3.18
2.4 80 27 3.00
3.05 100 34 2.95
3.7 120 41 2.92
4.35 140 48 2.90
5.7 180 63 2.84
7.3 220 81 2.72
9 260 100 2.60
10.6 297 118 2.52
12.5 0.5 20 6 3.20
1.05 40 13 3.05
1.6 60 20 3.00
2.2 80 28 2.91
2.8 100 35 2.86
3.4 120 43 2.82
4.1 140 51 2.73
5.4 180 68 2.67
6.8 220 85 2.59
8.5 260 106 2.45
10.4 300 130 2.31
12.5 352 156 2.25



KV6500
Stator Diameter 11mm Weight 7.5g
Stator Thickness 6mm Rotor Diameter 14.2mm
No.of Stator Slots 9 Body Length 13.6mm
No.of Rotor Poles 12 Max Lipo Cell 2S
Motor Kv 6500 ESC 15-20A
No-load current 0.7A/10V Recommended Prop(inch) 2030*3/3020*2/2035*4
Motor Resistance 95mΩ



Max Continuous Current 18A/30s
Max Continuous Power 225W



Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
DYS2030*3 11.1 0.85 20 9 2.12 60℃
1.75 40 19 2.06
2.7 60 30 2.00
3.7 80 41 1.95
4.7 100 52 1.92
5.7 120 63 1.90
7.1 140 79 1.78
9.3 184 103 1.78
12.5 0.8 20 9 2.25
1.8 40 20 2.00
2.6 60 33 1.85
3.5 80 44 1.83
4.5 100 56 1.78
5.45 120 68 1.76
6.4 140 80 1.75
8.3 180 104 1.73
10.1 217 126 1.72
GF2035*4 11.1 0.85 20 9 2.12 60℃
1.75 40 19 2.06
2.7 60 30 2.00
3.8 80 42 1.90
4.8 100 53 1.88
5.9 120 65 1.83
7.4 140 82 1.70
9.6 180 107 1.69
12.2 220 135 1.62
12.5 0.75 20 9 2.13
1.8 40 20 2.00
2.7 60 34 1.78
3.8 80 48 1.68
4.9 100 61 1.63
6 120 75 1.60
7.05 140 88 1.59
9.3 180 116 1.55
114 220 143 1.54
14.1 264 176 1.50
3020*2 11.1 0.6 20 7 3.00 60℃
1.3 40 14 2.77
2 60 22 2.70
2.8 80 31 2.57
3.5 100 39 2.57
5.2 140 58 2.43
6.8 180 75 2.38
8.5 220 94 2.33
10.3 260 114 2.27
13.1 300 145 2.06
14.6 331 162 2.04
12.5 0.5 20 6 3.20
1.2 40 15 2.67
1.9 60 24 2.53
2.6 80 33 2.46
3.4 100 43 2.35
4.9 140 61 2.29
6.6 180 83 2.18
8.3 220 104 2.12
10 260 125 2.08
12.1 300 151 1.98
15.1 340 189 1.80
17.25 387 216 1.79



KV8000
Stator Diameter 11mm Weight 7.5g
Stator Thickness 6mm Rotor Diameter 14.2mm
No.of Stator Slots 9 Body Length 13.6mm
No.of Rotor Poles 12 Max Lipo Cell 2S
Motor Kv 8000 ESC 15-20A
No-load current 0.9A/10V Recommended Prop(inch) 2030*3/3020*2/2035*4
Motor Resistance 112mΩ



Max Continuous Current 23A/30s
Max Continuous Power 287W



Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
3020*2 7.4 0.87 20 6 3.11 49℃
1.8 40 13 3.00
2.8 60 21 2.90
3.9 80 29 2.77
7.3 140 54 2.59
9.8 180 73 2.48
12.8 220 95 2.32
15.1 252 112 2.26
8.4 0.84 20 7 2.83
1.75 40 15 2.72
2.7 60 23 2.65
3.7 80 31 2.57
7 140 59 2.38
9.3 180 78 2.30
12 220 101 2.18
14.1 250 118 2.11
17.4 296 146 2.03
GF2035*4 7.4 1.13 20 8 2.39 65℃
2.4 40 18 2.25
3.8 60 28 2.13
5.3 80 39 2.04
6.8 100 50 1.99
8.25 120 61 1.97
9.9 140 73 1.91
12.4 171 92 1.86
8.4 1.1 20 9 2.16
2.3 40 19 2.07
3.6 60 30 1.98
5 80 42 1.90
9.3 140 78 1.79
10.9 160 92 1.75
12.8 180 108 1.67
14.7 202 123 1.64
11.1 0.9 20 10 2.00
1.9 40 21 1.90
3.1 60 34 1.74
4.4 80 49 1.64
8.6 140 95 1.47
11.4 180 127 1.42
14.2 220 158 1.40
16.9 260 188 1.39
20 295 222 1.33
12.5 0.8 20 10 2.00
1.8 40 23 1.78
2.9 60 36 1.66
4.1 80 51 1.56
8.4 140 105 1.33
11 180 138 1.31
22.5 341 281 1.21
DYS2030*3 7.4 1.1 20 8 2.46 53℃
2.3 40 17 2.35
3.5 60 26 2.32
4.7 80 35 2.30
8.7 143 64 2.22
8.4 1.1 20 9 2.16
2.2 40 18 2.16
3.4 60 29 2.10
4.6 80 39 2.07
8.1 140 68 2.06
10.1 172 85 2.03
11.1 0.9 20 10 2.00
1.9 40 21 1.90
3.1 60 34 1.74
4.2 80 47 1.72
7.4 140 82 1.70
9.6 180 107 1.69
13.38 250 149 1.68
12.5 0.8 20 10 2.00
1.9 40 24 1.68
2.9 60 36 1.66
4.1 80 51 1.56
7.4 140 93 1.51
9.6 180 120 1.50
15.4 287 193 1.49



[/TABS]
