$59.08
Availability: 4 In Stock
Sku: SS-V4008-380
Description
Sunnysky V series of motors are specially designed power for long-endurance multirotor aircraft. Designing style of the whole series are high efficiency, stable stable structure, light weight, high consistency etc..

These flat V series motors are designed for long flight time multirotors. These motors
can produce enough torque at low RPM and work at peak efficiency during flight.

The whole series uses Sunnysky patented Stepped and knurled design that not only
efficiently prevent motors from getting loose, but also reduce the probability of
malfunction and unstable output power. The whole series use original Japanese EZO
bearings that provide quiet and stable flight in the air.

With the guarantee of strength, the caps of V motors are highly hollow-cutted to save
weight, so that these motors can reach maximum thrust-to-weight ratio and gain more
flight time.

V series motors are tested with the strictest procedures of SunnySky?? QC protocols.
Each of these motors are dynamically balanced with our hightest standard. The axial
and radial runouts of each rotor are tested strictly according to its design. The
difference in performance of each motor is controlled within 3% so that these products
can provide precise and stable power for professional applications..

[TABS]OVERVIEW

KV380
Stator Diameter 40mm Rotor Diameter 44.3mm
Stator Thickness 8mm Body Length 20mm
No.of Stator Slots 18 Max Lipo Cell 4-6S
No.of Rotor Poles 24 ESC 30-40A
Motor Kv 380 Recommended Prop(inch) EOLO CN12*5/CN13*5/CN15*5.5/CN17*6.2
No-load current 0.5A/10V Recommended single take-off Weight ≤1000g
Motor Resistance 131mΩ
Max Continuous Current 20A/30s
Max Continuous Power 500W
Weight

105g

Prop(inch) Voltage(V) RPM Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
EOLO CN12*5 22.2 2983 0.7 200 16 12.87 68℃
3514 1.2 300 27 11.26
4020 1.7 400 38 10.60
4440 2.3 500 51 9.79
4785 2.9 600 64 9.32
5204 3.6 700 80 8.76
5568 4.3 800 95 8.38
5830 5 900 111 8.11
6167 5.8 1000 129 7.77
6964 8.4 1293 186 6.93
25 2993 0.6 200 15 13.33
3501 1.1 300 28 10.91
4008 1.5 400 38 10.67
4440 2 500 50 10.00
4780 2.6 600 65 9.23
5212 3.2 700 80 8.75
5624 3.8 800 95 8.42
5855 4.5 900 113 8.00
6172 5.2 1000 130 7.69
6738 6.8 1200 170 7.06
7662 10.2 1580 255 6.20
EOLO CN13*5 22.2 2483 0.6 200 13 15.02 83℃
2978 1 300 22 13.51
3367 1.5 400 33 12.01
3762 2 500 44 11.26
4124 2.6 600 58 10.40
4440 3.3 700 73 9.56
4716 4 800 89 9.01
4915 4.7 900 104 8.63
5232 5.4 1000 120 8.34
5757 7.05 1200 157 7.67
6109 8.9 1400 198 7.09
6704 11.2 1610 249 6.48
25 2465 0.5 200 13 16.00
2873 0.9 300 23 13.33
3379 1.3 400 33 12.31
3758 1.9 500 48 10.53
4125 2.4 600 60 10.00
4525 2.9 700 73 9.66
4782 3.5 800 88 9.14
5026 4.2 900 105 8.57
5282 4.9 1000 123 8.16
5760 6.4 1200 160 7.50
6250 7.9 1400 198 7.09
6621 9.8 1600 245 6.53
7015 11.7 1800 293 6.15
7283 13.1 1945 328 5.94
EOLO CN15*5.5 22.2 1915 0.5 200 11 18.02 100℃2min20s
2358 0.8 300 18 16.89
2656 1.3 400 29 13.86
3040 1.8 500 40 12.51
3267 2.3 600 51 11.75
3482 2.9 700 64 10.87
3716 3.5 800 78 10.30
3920 4.2 900 93 9.65
4131 4.9 1000 109 9.19
4504 6.35 1200 141 8.51
4816 8.15 1400 181 7.74
5185 9.9 1600 220 7.28
5450 12 1800 266 6.76
6013 16.4 2210 364 6.07
25 1932 0.4 200 10 20.00
2333 0.8 300 20 15.00
2679 1.2 400 30 13.33
2992 1.55 500 39 12.90
3281 2.1 600 53 11.43
3460 2.6 700 65 10.77
3726 3.1 800 78 10.32
3926 3.7 900 93 9.73
4166 4.4 1000 110 9.09
4513 5.7 1200 143 8.42
4868 7.2 1400 180 7.78
5186 8.9 1600 223 7.19
5469 10.7 1800 268 6.73
5730 12.6 2000 315 6.35
6035 14.8 2200 370 5.95
6443 19.4 2651 485 5.47
EOLO CN17*6.2 14.8 1545 0.7 200 10 19.31 75℃
1873 1.2 300 18 16.89
2142 1.7 400 25 15.90
2403 2.4 500 36 14.08
2579 3.1 600 46 13.08
2770 3.8 700 56 12.45
2956 4.6 800 68 11.75
3090 5.5 900 81 11.06
3294 6.5 1000 96 10.40
3548 8.5 1200 126 9.54
3859 10.8 1400 160 8.76
4078 13 1570 192 8.16
16 1541 0.6 200 10 20.83
1830 1.1 300 18 17.05
2086 1.6 400 26 15.63
2335 2.2 500 35 14.20
2505 2.9 600 46 12.93
2723 3.55 700 57 12.32
2883 4.3 800 69 11.63
2965 5.1 900 82 11.03
3177 6 1000 96 10.42
3548 7.9 1200 126 9.49
3771 10.05 1400 161 8.71
4058 12.5 1600 200 8.00
4236 14.4 1770 230 7.68

KV600
Stator Diameter 40mm Rotor Diameter 44.3mm
Stator Thickness 8mm Body Length 20mm
No.of Stator Slots 18 Max Lipo Cell 4S
No.of Rotor Poles 24 ESC 40A
Motor Kv 600 Recommended Prop(inch) EOLO CN13*5/CN15*5.5
No-load current 0.8A/10V Recommended single take-off Weight ≤800g
Motor Resistance 75mΩ
Max Continuous Current 30A/30s
Max Continuous Power 480W
Weight

104g

Prop(inch) Voltage(V) RPM Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
EOLO CN13*5 14.8 2511 1 200 15 13.51 75℃
2960 1.6 300 24 12.67
3429 2.4 400 36 11.26
3808 3.3 500 49 10.24
4188 4.2 600 62 9.65
4440 5.3 700 78 8.92
4757 6.3 800 93 8.58
5046 7.35 900 109 8.27
5317 8.5 1000 126 7.95
5702 11.1 1200 164 7.30
6505 16.4 1550 243 6.39
16 2470 0.9 200 14 13.89
2951 1.6 300 26 11.72
3381 2.3 400 37 10.87
3716 3 500 48 10.42
4157 3.9 600 62 9.62
4489 4.8 700 77 9.11
4725 5.8 800 93 8.62
5041 6.8 900 109 8.27
5272 7.8 1000 125 8.01
5817 10.2 1200 163 7.35
6173 13 1400 208 6.73
6916 18.3 1760 293 6.01
EOLO CN15*5.5 14.8 1931 0.8 200 12 16.89 85℃
2337 1.4 300 21 14.48
2725 2.1 400 31 12.87
3025 2.9 500 43 11.65
3258 3.7 600 55 10.96
3535 4.6 700 68 10.28
3741 5.6 800 83 9.65
3972 6.6 900 98 9.21
4133 7.6 1000 112 8.89
4583 10.15 1200 150 7.99
4846 12.9 1400 191 7.33
5208 16.1 1600 238 6.71
5456 19.5 1800 289 6.24
5757 23.4 2029 346 5.86
16 1950 0.8 200 13 15.63
2358 1.3 300 21 14.42
2706 2 400 32 12.50
3002 2.7 500 43 11.57
3306 3.4 600 54 11.03
3562 4.3 700 69 10.17
3776 5.3 800 85 9.43
3915 6.2 900 99 9.07
4260 7.15 1000 114 8.74
4519 9.4 1200 150 7.98
4865 12 1400 192 7.29
5178 14.8 1600 237 6.76
5466 18.6 1800 298 6.05
5728 21.3 2000 341 5.87
6048 26.2 2276 419 5.43

[/TABS]

Orders are shipped from Columbus, the capital city of Ohio, USA.

An order placed before 2:00pm Eastern Standard Time will be shipped the same working day.

We ship on Monday-Friday by US postal service (USPS) and UPS, and Saturday morning by USPS if a local post office is open. Any order placed on Saturday morning may or may not be shipped the same day. Orders placed on Sunday and US holidays will be shipped the next working day.

Domestic:

Retail orders above $80 may be eligible for free shipping, including contiguous United States, Alaska, Guam, Hawaii, Puerto Rico, and APO addresses. We will use either USPS or UPS that most packages can be delivered in 3-5 working days, but not guaranteed. However, for packages contain large and heavy items, such as power supply, we may use parcel post service or UPS Surepost that may take up to 7 working days to be delivered.

USPS First Class Mail and Priority Mail, Express Mail, and UPS services can be used for domestic addresses. Tracking number and delivery confirmation will be provided to the customer when they are available. If you have not received a tracking information E-mail, please log into your account and click the "view order" link, then click "Track your order" link to find out the tracking number and ship method.

USPS Priority Mail is typically delivered in 3 working days. But very occasionally a priority mail package may be delayed for several days in the mailing system. If delivery time is extremely critical to your order, we would recommend Priority Mail Express or other couriers.

Domestic First Class Mail is only 1-2 days slower than Priority Mail in delivery. We suggest domestic customers choose First Class Mail for an order under 15 oz to save shipping cost.

Real shipping cost is calculated according to package weight and distance, and can be found in the checkout page after delivery address is specified in the fields.

Any order of $200 and above requires addressee's signature confirmation upon receipt of the package. Please contact us in advance or leave a comment in the message box if you want to waive signature confirmation.

We always check the legality of potential fraudulent orders. This procedure may lead to 1-2 working days delay in shipping in some rare cases.

We do not ship products to shipping forwarding companies. Any order shows this kind of address will be cancelled and refunded without notification.

International:

DHL, DHL Express, US Postal Service (USPS) First Class Mail, Priority Mail, and Express Mail (EMS), and UPS services can be selected for international addresses. Shipping cost is calculated according to package weight and distance, and can be found in the check out process. A package usually takes around 7-10 days to be delivered, or occasionally up to 45 days depending on the processing speed in your country, especially in some countries such as Brazil and Russia.

USPS First Class Mail is a budget shipping method. As soon as a First Class Mail package left USPS Chicago hub there will be no tracking information available. If you need detailed tracking information and timely delivery please do not use this shipping method.

Presently we cannot ship lithium batteries internationally by US Post Service or any other air shipping method. Please select UPS Ground if your order contains LiPo or LiFe battery.

We do not ship products to shipping forwarding companies. Any order shows this kind of address will be cancelled and refunded without notification.

SunnySky V4008 High Efficiency Brushless Motors
