$78.46
Availability: 23 In Stock
Sku: SS-V5208-340
Description
Sunnysky V series of motors are specially designed power for long-endurance multirotor aircraft. Designing style of the whole series are high efficiency, stable stable structure, light weight, high consistency etc..

These flat V series motors are designed for long flight time multirotors. These motors
can produce enough torque at low RPM and work at peak efficiency during flight.

The whole series uses Sunnysky patented Stepped and knurled design that not only
efficiently prevent motors from getting loose, but also reduce the probability of
malfunction and unstable output power. The whole series use original Japanese EZO
bearings that provide quiet and stable flight in the air.

With the guarantee of strength, the caps of V motors are highly hollow-cutted to save
weight, so that these motors can reach maximum thrust-to-weight ratio and gain more
flight time.

V series motors are tested with the strictest procedures of SunnySky?? QC protocols.
Each of these motors are dynamically balanced with our hightest standard. The axial
and radial runouts of each rotor are tested strictly according to its design. The
difference in performance of each motor is controlled within 3% so that these products
can provide precise and stable power for professional applications..

[TABS]OVERVIEW

KV340
Stator Diameter 52mm Rotor Diameter 59mm
Stator Thickness 8mm Body Length 23mm
No.of Stator Slots 24 Max Lipo Cell 4-6S
No.of Rotor Poles 28 ESC 60A
Motor Kv 340 Recommended Prop(inch) EOLO CN15*5.5/CN17*6.2/C18/C20
No-load current 0.8A/10V Recommended single take-off Weight ≤1500g
Motor Resistance 78mΩ
Max Continuous Current 35A/30s
Max Continuous Power 880W
Weight

175g

Prop(inch) Voltage(V) RPM Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
EOLO CN15*5.5 22.2 2978 2 500 44 11.26 50℃
3619 3.25 750 72 10.40
4199 4.9 1000 109 9.19
4667 6.7 1250 149 8.40
5028 8.6 1500 191 7.86
5426 10.6 1750 235 7.44
5963 14.5 2130 322 6.62
25 3000 1.8 500 45 11.11
3673 3 750 75 10.00
4144 4.35 1000 109 9.20
4615 6 1250 150 8.33
5037 7.7 1500 193 7.79
5415 9.7 1750 243 7.22
5778 11.8 2000 295 6.78
6095 14.1 2250 353 6.38
6596 17.8 2670 445 6.00
EOLO CN17*6.2 22.2 2345 1.7 500 38 13.25 65℃
2860 2.9 750 64 11.65
3211 4.3 1000 95 10.48
3605 5.8 1250 129 9.71
3872 7.5 1500 167 9.01
4248 9.4 1750 209 8.39
4510 11.5 2000 255 7.83
4807 13.7 2250 304 7.40
5027 16.1 2500 357 6.99
5280 18.7 2750 415 6.62
5583 21.8 3078 484 6.36
25 2344 1.6 500 40 12.50
2837 2.6 750 65 11.54
3218 3.8 1000 95 10.53
3627 5.15 1250 129 9.71
3935 6.7 1500 168 8.96
4225 8.5 1750 213 8.24
4567 10.25 2000 256 7.80
4763 12.25 2250 306 7.35
5040 14.4 2500 360 6.94
5288 16.6 2750 415 6.63
5520 19 3000 475 6.32
6127 25.8 3683 645 5.71
EOLO C18 22.2 2186 1.6 500 36 14.08 97℃
2663 2.7 750 60 12.51
3022 4.1 1000 91 10.99
3459 5.6 1250 124 10.05
3740 7.3 1500 162 9.26
4043 9.1 1750 202 8.66
4294 11.05 2000 245 8.15
4513 13.4 2250 297 7.56
4783 15.7 2500 349 7.17
5019 18.3 2750 406 6.77
5479 23.6 3300 524 6.30
25 2200 1.5 500 38 13.33
2669 2.5 750 63 12.00
3046 3.7 1000 93 10.81
3450 5.1 1250 128 9.80
3745 6.6 1500 165 9.09
4070 8.2 1750 205 8.54
4300 10 2000 250 8.00
4546 11.8 2250 295 7.63
4775 13.85 2500 346 7.22
5029 16.1 2750 403 6.83
5241 18.4 3000 460 6.52
5638 23.5 3500 588 5.96
5958 28.1 3970 703 5.65
EOLO C20 22.2 1808 1.5 500 33 15.02 119℃ 2min
2246 2.6 750 58 12.99
2605 3.8 1000 84 11.85
2887 5.2 1250 115 10.83
3128 6.9 1500 153 9.79
3422 8.6 1750 191 9.17
3635 10.4 2000 231 8.66
3853 12.55 2250 279 8.08
4066 14.8 2500 329 7.61
4277 17.5 2750 389 7.08
4407 19.6 3000 435 6.89
4742 25.4 3500 564 6.21
5113 30.6 3970 679 5.84
25 1855 1.4 500 35 14.29
2273 2.3 750 58 13.04
2586 3.4 1000 85 11.76
2841 4.7 1250 118 10.64
3189 6.2 1500 155 9.68
3410 7.6 1750 190 9.21
3605 9.5 2000 238 8.42
3873 11.2 2250 280 8.04
4064 13.2 2500 330 7.58
4289 15.4 2750 385 7.14
4472 17.8 3000 445 6.74
4828 22.6 3500 565 6.19
5109 28.4 4000 710 5.63
5540 36.2 4710 905 5.20

[/TABS]
