Description
Recommended propellers for the motor are as follows:
- 4S LiPo with 15x8 or 15x10
- 6S LiPo with 13x6 or 13x6.5
Motor specifications:
- KV: 720
- Configuration: 12N14P
- Stator Diameter: 35mm
- Stator Length: 30mm
- Shaft Diameter: 6mm
- Motor Dimension (Dia. x length): Φ43×55mm
- Weight: 287g
- Idle current (10)@10v(A): 1.5
- No. of Cells (LiPo): 3-6S
- Max Continuous current (A) 180 Second: 68A
- Max Continuous Power (W) 180 Second: 1350W
- Max. efficiency current (17-42A): >78%
- Internal resistance: 23mΩ
